ZARN75155-TV INA Complex Bearings
category
Complex Bearings
INA ZARN75155-TV SPECIFICATIONS
- INA
ZARN75155-TV
- Negotiation
- Negotiation
-
Qishun Industrial Manufacture Co.,Limited.2020-07-10 09:46:19
Welcome to my shop! Glad to serve you! Please send your question!
INA ZARN75155-TV Product Description
 |  |  | |
| Name | ZARN75155-TV | KEE275108/K275155 | T-EE275109D/275155+A |
| Brand | INA | ISB | NTN |
| Size (mm) | 75x155x100(mm) | 273.05x393.7x73.817(mm) | 276.225x393.7x130.175(mm) |
| Bore Diameter (mm) | 75(mm) | 273,05(mm) | 276,225(mm) |
| Outer Diameter (mm) | 155(mm) | 393,7(mm) | 393,7(mm) |
| Width (mm) | 100(mm) | 73,817(mm) | 130,175(mm) |
| d | 75 mm 2.9528 in | 273,05 mm 10.75 in | 276,225 mm 10.875 in |
| D | 155 mm 6.1024 in | 393,7 mm 15.5 in | 393,7 mm 15.5 in |
| H | 100 mm 3.937 in | ||
| B | 21 mm 0.8268 in | 69,85 mm 2.75 in | |
| C | 30 mm 1.1811 in | 50,005 mm 1.9687 in | |
| D1 | 135 mm 5.315 in | ||
| Da max | 136 mm 5.3543 in | ||
| da min | 113 mm 4.4488 in | ||
| H1 | 65 mm 2.5591 in | ||
| r1 min | 1 mm 0.0394 in | ||
| rmin | 0,3 mm 0.0118 in | ||
| m | 7,9 kg / Weight | ||
| Ca | 290000 N / Dynamic load rating (axial) | ||
| C0a | 890000 N / Static load rating (axial) | ||
| Cr | 72000 N / Dynamic load rating (radial) | ||
| C0r | 132000 N / Static load rating (radial) | ||
| nG Ol | 2100 1/min / Limiting speed for oil lubrication (valid only with adequate oil cooling) | ||
| nG Fett | 700 1/min / Limiting speed for grease lubrication | ||
| MRL | 8 Nm / Bearing frictional torque | ||
| caL | 6600 N/µm / Axial rigidity | ||
| ckL | 8500 Nm/mrad / Tilting rigidity | ||
| Mm | 149 kg x cm^2 / Mass moment of inertia for rotating inner ring | ||
| AM75 / Designation of recommended INA locknut | |||
| MA | 580 Nm / Tightening torque (Only valid in conjunction with INA precision locknuts) |
